EB-PBFSource: ALD Vacuum TechnologiesALD Vacuum Technologies EBuild
Industrial electron-beam powder-bed system with a movable build chamber.
Source reviews: 2026-10-17.
Specifications are reported claims, not independent test results.
The details that matter.
Published specifications for this model. Follow a field's source for its configuration and measurement conditions; older fields refer to the profile's reference list.
| Introduction year | Not verified |
|---|---|
| Model family | EBuild |
| Process | EB-PBF |
| Build envelope (X × Y × Z) | 850 × 850 × 1000 mm |
| Nominal box volume | 722.50 L · calculated from the envelope |
| Enclosure | Not verified |
| Materials cited in this profile | Metal powder |
| Manufacturer listing status | Manufacturer product page listed; stock and regional availability not established |
| Regional stock and price | Check the manufacturer |
| Market grouping | Industrial · editorial grouping |
Technical specifications
| Beam Power Max (kW) | 45 |
|---|---|
| Acceleration Voltage Max (kV) | 150 |
| Layer Thickness | 50–100 µm typical |
| Powder Bed Capacity Tonnes | 15 |
System and configuration
EBuild moves its build chamber between the process and extraction stations. The manufacturer specifies up to 45 kW beam power and a withdrawal system supporting a powder bed of up to 15 tonnes; that is not a finished-part payload.
Explore the model family.
An exact introduction year has not been established in the reviewed sources.
Family: EBuild · Listing status only
Explore ALD Vacuum Technologies through the generationsRead this with the specifications
The current page calls the system EBuild; the EBuild850 designation occurs in a separate brochure. Not counted twice.
A larger nominal envelope does not establish better print quality. Fit depends on the configuration, usable area, supports, and orientation.
