Ultrasonic sheet laminationManufacturer image: FabrisonicFabrisonic SonicLayer 1200
Ultrasonic additive manufacturing machine for small-scale metal production and research, including embedded components.
Source reviews: 2026-10-16.
Specifications are reported claims, not independent test results.
The details that matter.
Published specifications for this model. Follow a field's source for its configuration and measurement conditions; older fields refer to the profile's reference list.
| Introduction year | Not verified |
|---|---|
| Model family | Ultrasonic sheet lamination |
| Process | Ultrasonic sheet lamination |
| Build envelope (X × Y × Z) | Not verified |
| Nominal box volume | Not verified |
| Enclosure | Not verified |
| Materials cited in this profile | Metal foil, Aluminum, Copper |
| Manufacturer listing status | Official documentation available; current order availability not confirmed |
| Regional stock and price | Check the manufacturer |
| Market grouping | Industrial · editorial grouping |
Technical specifications
| Ultrasonic Power (W) | 2000 |
|---|---|
| Welding Force (lb) | 650 |
| Maximum Welding Speed | 120 in/min |
| Spindle Speed (rpm) | 7500 |
| Spindle | Tormach R8 |
| Table Dimensions (inches) | 16 × 10.5 |
| Machine Footprint (ft) | 4, 5.8 |
| Machine Height (inches) | 76 |
| Axis Positioning Accuracy | ±0.0002 in Linear positioning specification; do not equate with finished-part accuracy. |
| Axis Repeatability | 0.0001 in Machine-axis repeatability. |
| Sonotrode Material | Steel |
| Work Envelope (mm) | 254 × 254 × 254 Exact conversion of 10 × 10 × 10 in powered-axis work travel; not a guaranteed usable deposition volume. |
Solid-state metal lamination
SonicLayer 1200 bonds metal foils using ultrasonic vibration without melting them. Alternating foil deposition and CNC machining can create internal channels or embed sensors, and the manufacturer describes joining dissimilar metals.
Small-system envelope
The exact 1200 model has a 10 × 10 × 10 in work envelope. Larger dimensions elsewhere in the brochure refer to other SonicLayer products. Positioning accuracy and repeatability are linear-axis specifications, not a blanket tolerance for printed parts.
Explore the model family.
An exact introduction year has not been established in the reviewed sources.
Family: Ultrasonic sheet lamination · Listing status only
Explore Fabrisonic through the generationsRead this with the specifications
The brochure labels the 10 × 10 × 10 in envelope as powered-axis travel. Its exact metric equivalent, 254 × 254 × 254 mm, is retained as a work envelope; a guaranteed usable deposition volume is not established.
A larger nominal envelope does not establish better print quality. Fit depends on the configuration, usable area, supports, and orientation.
